C-TEC 2 Zone Conventional Fire Panel (LPCB Approved)
Approvals/certifications: Certifed to EN54 Parts 2 & 4 by the LPCB., Certified to EN54-13 by Kiwa Telefication.
Mains supply: 230V 50/60Hz.
Ma...
Approvals/certifications: Certifed to EN54 Parts 2 & 4 by the LPCB., Certified to EN54-13 by Kiwa Telefication.
Mains supply: 230V 50/60Hz.
Mains rated current:350mA maximum.
Internal power supply: 19V-28.5V (27V nominal). Ripple 7V maximum (battery fault).
Total output current limited to: 1.5A @ 230Vac (ImaxA eq 146mA).
Product dimensions (mm): 380 W x 235 H x D 96mm (hole required for flush mounting = 367 W x 220 H x 75 D mm. No bezel required).
In Stock
| Store | Stock |
|---|---|
| Qvis Technology Centre Ireland | 2 |
SKU
CFP702-4
Product Details
- Certified to EN54 parts 2, 4 and 13, C-TEC’s CFP 2 zone conventional fire alarm panel offers an array of user and installer-friendly features at a very competitive price.
- Supplied in an attractive flush or surface mountable plastic enclosure, it includes two detector zones, four conventional sounder circuits, class change and alert inputs, on-board fire and fault relays and combined keypad/keyswitch entry.
- A wide range of engineering functions are also provided including selectable zone delays, coincidence and non-latching zone facilities.
- Comprehensive test and fault finding facilities are also provided.
- Optional repeaters and relay expansion boards also available.
| Manufacturer | C-Tec |
|---|
