Approvals/certifications: Certified to EN54-3 & 23 by the LPCB & VdS Protocol/compatibility: Compatible with C-TEC's CFP, FP, MFP and EP203 conventional fire alarm panels and virtually all other makes (testing on third-party panels is recommended before use) Application/operation: Designed to be ceiling mounted – either stand-alone with a red or white cap or as part of a stacked Sounder/VAD/Detector Base combination VAD category & coverage: C-3-8.5 (151m3 cylindrical coverage) Flash rate & colour: 0.5Hz; 1Hz or OFF / White Supply/operating voltage: 18 to 30V DC Nominal SPL (Sound Pressure Level): 96dB(A) Alarm current: At 30Vdc: 12.2mA (0.5Hz) or 19.5mA (1Hz); At 18Vdc: 14.5mA (0.5Hz) or 25mA (1Hz) Product dimensions (mm): 122 x 46 (not including optional detector and base) IP Rating: IP21C (Type A) Weight: 170g Operating conditions/temperature: -10 to 55ºC Notes: For compliance to EN54-3 & EN54-23, the BF431QCP Quick Connect Plate must be used with the base device
