Viper Support
Quick guides across common fixes, firmware and setup. Tap a card to open the full walkthrough.
Fixes & Firmware
Troubleshooting steps and firmware downloads for Viper DVR and NVR systems.
No image on screen (NVR & DVR)
Hold the right mouse button down for ~8 seconds (until you hear a beep), this will force change the resolution.
Repeat up to 4 times until image is displayed.
No online connection via Powerline Adaptor (NVR & DVR)
Connect the recorder LAN port directly to a router LAN port via Ethernet.
Login to the recorder, navigate to: "Settings" > "Network" > "TCP/IP" >Enable "Obtain IP automatically". Once the recorder obtains new IP settings (IPv4 address will likely change from the default: 192.168.1.200) take recorder back to the powerline adaptor and reconnect.
Recorder not online when a new broadband router is fitted. (NVR & DVR)
Login to the recorder, navigate to "Settings" > "Network" > "TCP/IP", deselect "Obtain IP automatically" click Apply, then re-select it and click Apply again. This prompts the recorder to find new IP settings from the new router.
No camera audio on DVR
Login to the recorder, navigate to "Main menu" > "Camera" > "Camera Signal". Locate the "Audio Over Coax" column and enable for each camera requiring audio.
No image from a Dahua camera on Viper DVR
Login to the recorder, navigate to "Settings" > "Camera" > "Camera signal" - change the "signal type" for the Dahua camera channel to CVI. If the Viper DVR does not support CVI, the camera needs to be manually changed to TVI mode using a Dahua DVR or Test Monitor.
How to confirm a recorders firmware code:
Login to the recorder and navigate to "Settings > System > Information", next to "about this machine" click "View". The firmware code is shown in the firmware version number as highlighted here:
Note: replace the image path above with the uploaded screenshot once available in the Magento media library.
| DVR Model | Firmware Code | Version/Download | Notes |
|---|---|---|---|
| D1E | 1.4.5Download | Release 86853 |
| D1G | 1.4.5Download | Release 86853 |
| D1F | 1.4.5Download | Release 87704 |
| D0E | 1.4.5Download | Release 86853 |
| VIPER-4K2-32 | D2E | 1.4.5Download | Release 86853 |
| D28 | 1.3.8Download | Release 75871: Support for TVI 16:9 Cameras |
| D0D | 1.3.8Download | Release 72144: Support for TVI 16:9 Cameras |
| D0B | 1.3.8Download | Release 84588: Support for TVI 16:9 Cameras |
| VIPER-5MPL2-4 | D0C | 1.3.8Download | Release 68815: Support for TVI 16:9 Cameras |
| D1C | 1.3.8Download | Release 88951 (2026 patch): Support for TVI 16:9 Cameras |
| VIPER-5MPLITE-8 | D1D | 1.3.8Download | Release 77704: Support for TVI 16:9 Cameras |
| VIPER-4K-8 | D14 | 1.3.8Download | Final Release 52255: End of Support |
| D03 | 1.3.8Download | Final Release 52255: End of Support |
| D44 | 1.3.8Download | Final Release 64730: End of Support |
| VIPER-4K-32 | D05 | 1.3.8Download | Final Release 55594: End of Support |
| D00 | 1.3.8Download | Final Release 47995: End of Support |
To update via USB:
- Download the Firmware
- Transfer the firmware file to a USB drive formatted as FAT32
- Connect the USB drive to a front or back USB port of the recorder
- Reboot the recorder
- The Firmware upgrade will begin automatically, do not power off or unplug the system during the upgrade process
Update via PC/Laptop:
How to confirm a recorders firmware code:
Login to the recorder and navigate to "Settings > System > Information", next to "about this machine" click "View". The firmware code is shown in the firmware version number as highlighted here:
Note: replace the image path above with the uploaded screenshot once available in the Magento media library.
| NVR Model | Firmware Code | Version/Download | Notes |
|---|---|---|---|
| N0L | 1.4.11Download | Release 74500 |
| N0W | 1.4.14Download | Release 88630 |
| N0Z | 1.4.14Download | Release 86766 |
| N3V | 1.4.14Download | Release 87071 |
| N0R | 1.4.12Download | Release 82058 |
| VIPER-NVR-AI3-8 | N0A | 1.4.14Download | Release 86766 |
| N4I | 1.4.12Download | Release 82058 |
| N0N | 1.4.12Download | Release 82058 |
| VIPER-NVR-DL-4K-8 | N2P | 1.4.12Download | Release 84683 |
| VIPDL-NVR-AI-64 | N5I | 1.4.3Download | Release 66596: supported, version number 1.4.3 does not reflect feature set |
| VIPER-NVR-AI8-N-32 | N2I | 1.4.12Download | Release 82058 |
| N0Y | 1.4.14Download | Release 87287 |
| VIPER-NVR-AI8-N2-32 | N1W | 1.4.14Download | Release 87611 |
| N0I | 1.4.6Download | Final Release 56610: End of Support |
| N0K | 1.4.4Download | Final Release 42665: End of Support |
To update via USB:
- Download the Firmware
- Transfer the firmware file to a USB drive formatted as FAT32
- Connect the USB drive to a front or back USB port of the recorder
- Reboot the recorder
- The Firmware upgrade will begin automatically, do not power off or unplug the system during the upgrade process
